  1. Home
  2. /Technologies
  3. /Intel Foveros

2

2.5D chiplet assembly on silicon interposer or redistribution-layer fan-out (Foveros-S and Foveros-R)

3D STACKING WITH

3D stacking with copper-to-copper hybrid bonding (Foveros Direct 3D)

APPLICATIONS

AI & HPC · Data Center · Consumer Electronics

Official technology image

2

2.5D chiplet assembly on silicon interposer or redistribution-layer fan-out (Foveros-S and Foveros-R)

3D STACKING WITH

3D stacking with copper-to-copper hybrid bonding (Foveros Direct 3D)

APPLICATIONS

AI & HPC · Data Center · Consumer Electronics

Public source

Intel Foveros

Advanced Packaging

Intel Foveros is a family of advanced packaging technologies used to place and interconnect multiple dies in one package.

  • AI & HPC
  • Data Center
  • +1
United StatesView Official Source (opens in a new tab)

Official technology image

Overview

Intel Foundry 3D stacking and 2.5D chiplet packaging family, including hybrid-bonding options described as Foveros Direct 3D. EMIB is a separate 2.5D bridge platform.

Public Intel Foundry pages describe Foveros-S 2.5D assembly on a silicon interposer, Foveros-R 2.5D using redistribution-layer fan-out, and Foveros Direct 3D, which uses copper-to-copper hybrid bonding for vertical stacking. Those named Foveros variants remain capabilities of this family rather than separate listings. Intel also notes compatibility with chiplet interconnect approaches such as UCIe. EMIB, a silicon-bridge 2.5D interconnect described on the same Foundry packaging pages, is listed independently. Process options, design rules and current availability should be confirmed on Intel’s official packaging pages.

Capabilities

Key characteristics associated with this technology.

  • 2.5D chiplet assembly on silicon interposer or redistribution-layer fan-out (Foveros-S and Foveros-R)

  • 3D stacking with copper-to-copper hybrid bonding (Foveros Direct 3D)

  • Described as compatible with chiplet interconnect approaches such as UCIe

  • Distinct from Intel EMIB, which is a separate 2.5D embedded-bridge platform

Organization

Intel Corporation

United States

View organization

Official resources

  • Advanced Packaging Innovations | Chip Packagesintel.com (opens in a new tab)

Source & disclosure

Independent discovery listing. This profile was prepared from publicly available information published by the organization. For the latest and complete technical information, refer to the official company source.

Official source

intel.com (opens in a new tab)

Last source check

Aug 31, 2026

Notice something that needs updating?

Report a correction
