OVEN-CONTROLLED CRYSTAL OSCILLATORS
Oven-controlled crystal oscillators (OCXO)
Oven-controlled crystal oscillators (OCXO)
VN01, VN03, VN04 and VN05 series packages
Industrial · Telecommunications · Aerospace & Defense
Public source
PDI VN Series OCXO is the oven-controlled crystal oscillator family published on Wi2Wi's OCXO page under the Precision Devices brand.
Silicon Showcase illustrative visual
Illustrative representation based on publicly available technical information.
Wi2Wi PDI brand oven-controlled crystal oscillator series (VN01–VN05) with published low / ultra-low phase-noise options.
Wi2Wi describes PDI OCXOs with ultra-low phase noise, high vibration tolerance, popular packages and double hermetically sealed quartz crystals, offered in standard and custom frequencies. The official table lists VN01 (thru-hole sinewave into 50 ohms, 5–100 MHz, 35.5 × 25.4 mm), VN03 (thru-hole sinewave into 50 ohms, 5–100 MHz, 25.4 × 25.4 mm), VN04 (thru-hole/gull wing HCMOS/LVCMOS, 10–50 MHz, ultra-low phase noise) and VN05 (SMD TTL/CMOS/sinewave, 10–50 MHz). This listing records the VN series as a Wi2Wi PDI brand family.
Key characteristics associated with this technology.
Oven-controlled crystal oscillators (OCXO)
VN01, VN03, VN04 and VN05 series packages
Published low / ultra-low phase-noise options
PDI brand family from Wi2Wi
